Pos Panduan Bushing Perunggu
Bronze Bushing Guide Post combines a precision-machined guide pillar with a durable bronze bushing to create a dependable guiding solution for molds and die systems. The assembly is designed to deliver smooth linear movement, posisi stabil, and reduced surface wear during repeated operation. Its optimized material combination enhances operational efficiency while supporting consistent performance in demanding industrial environments. Suitable for both standard and custom tooling applications, it provides reliable guidance for long-term production requirements.
- Kontrol Gerak Linier Halus: Ensures stable guidance throughout repeated cycles.
- Durable Bronze Bushing Structure: Enhances reliability under continuous operating conditions.
- Reduced Wear Between Components: Helps extend service life of tooling.
- Suitable For Heavy Duty Applications: Supports demanding industrial mold systems.
Deskripsi Produk
Pendahuluan
Bronze Bushing Guide Post is a precision guiding assembly designed for stamping dies, dasar cetakan, cetakan injeksi, dan sistem alat industri. Combining a hardened steel guide post with a high-quality bronze bushing, this assembly provides accurate linear guidance and stable movement between critical mold components. It helps maintain precise alignment during operation, reducing mechanical deviation and supporting consistent production quality across a wide range of manufacturing applications.
The guide post is manufactured from premium bearing steel and undergoes precision grinding and heat treatment to achieve excellent hardness and dimensional accuracy. The bronze bushing offers superior anti-friction properties and smooth sliding performance, helping reduce wear between moving components. This combination creates a reliable guiding system capable of operating efficiently under continuous production conditions while minimizing maintenance requirements and extending tooling service life.
Bronze Bushing Guide Posts are widely used in automotive molds, alat komponen elektronik, household appliance manufacturing, metal stamping dies, cetakan injeksi plastik, dan peralatan industri presisi. Available in multiple sizes and configurations, they can accommodate different load requirements and mold structures. Dimensi khusus, bahan-bahan, and surface treatments are available to meet specific OEM and industrial applications, providing long-term reliability and dependable performance in demanding production environments.
Spesifikasi
| Parameter | Spesifikasi |
|---|---|
| Nama Produk | Pos Panduan Bushing Perunggu |
| Materi Pos Panduan | SUJ2 / GCr15 Baja Bantalan |
| Bahan Bushing | Perunggu Kekuatan Tinggi |
| Permukaan Akhir | Tanah Presisi |
| Kekerasan | HRC 58-62 |
| Kisaran Diameter | Ø16 mm – Ø80 mm |
| Rentang panjang | 80 mm – 600 mm |
| Jenis Pemandu | Panduan Bushing Perunggu |
| Perawatan Permukaan | Chrome Keras Opsional |
| Kelurusan | ≤0.005 mm/100 mm |
| Jenis Instalasi | Tekan Fit |
| Kelas Presisi | Presisi Tinggi |
| Kehidupan pelayanan | Penggunaan Industri Jangka Panjang |
| Kustomisasi | OEM & ODM tersedia |
Tiga Aspek Kustomisasi Utama, Disesuaikan dengan Kebutuhan Anda
Mencocokkan berbagai metode kustomisasi untuk memenuhi berbagai kebutuhan.
Manufaktur Presisi, Kualitas Luar Biasa
Kinerja Geser Pelumas Sendiri
The bronze bushing structure promotes smooth sliding contact, helping reduce lubrication dependence while supporting reliable operation in continuous manufacturing environments.
Penyerapan Getaran yang Efektif
Bronze material helps absorb operational vibration and minor impact forces, contributing to smoother equipment movement and improved tooling stability during production.
Distribusi Beban Seimbang
Designed to distribute operating loads evenly across guiding surfaces, helping reduce localized stress concentrations and supporting long-term component reliability.
Kemampuan anti-kejang yang sangat baik
The combination of hardened steel and bronze materials minimizes the risk of surface sticking, ensuring dependable movement under varying operating conditions.
Layanan Berkualitas, Waktu pengiriman yang dipersingkat
Dari tinjauan desain hingga pengiriman, Kami menyediakan tindak lanjut satu lawan satu khusus selama seluruh proses.
Konsultasi → Menyediakan Gambar → Tinjauan Desain & Penawaran → Pemrosesan Pesanan → Inspeksi Kualitas → Pengiriman Tepat Waktu → Tindak Lanjut Purna Jual
Keuntungan kami
Didukung oleh pengalaman teknik lebih dari 25 tahun, Tim kami menawarkan layanan komprehensif—mulai dari desain cetakan yang disesuaikan dan pemesinan presisi hingga produksi skala penuh—didukung oleh sistem jaminan kualitas yang kuat dan layanan pelanggan yang proaktif. Bersertifikat di bawah ISO9001, ISO14001, dan IATF 16949, Kami terus berupaya mencapai keunggulan dalam kualitas, inovasi, dan kepuasan pelanggan.
Lebih dari 100,000 unit tersedia, dengan pengiriman 2 jam untuk produk standar.
Menerapkan sistem inspeksi tiga tahap—pemeriksaan material awal, inspeksi dalam proses, dan inspeksi akhir.
Inventaris besar dan proses cepat, Menjamin pengiriman tepat waktu dengan inspeksi produk 100%.
Rentang Aplikasi
Pilihan utama di berbagai industri.
Pertanyaan yang diajukan
What is a Bronze Bushing Guide Post?
A Bronze Bushing Guide Post is a guiding assembly that combines a hardened steel guide post with a bronze bushing. It is used to provide accurate alignment and smooth movement in molds and die systems.
What are the advantages of a bronze bushing?
Bronze bushings offer low friction, good wear resistance, smooth sliding performance, and excellent load-carrying capability. They help improve guiding accuracy and extend component service life.
Where is a Bronze Bushing Guide Post commonly used?
Cetakan ini banyak digunakan dalam cetakan stamping, cetakan injeksi, dasar cetakan, cetakan progresif, sistem perkakas industri, cetakan otomotif, dan peralatan manufaktur presisi.
Can Bronze Bushing Guide Posts be customized?
Iya. Diameter khusus, panjang, bushing materials, perlakuan permukaan, and mounting configurations can be manufactured according to customer drawings and application requirements.
How does a Bronze Bushing Guide Post improve tooling performance?
It helps maintain precise alignment, reduces friction between moving parts, minimizes component wear, supports smooth operation, and improves the overall reliability of mold and die assemblies.
